The base is composed by two removable sections made of zinc coated steel hooked to plastic supports.

The four holes are equipped with holes as push handle and for placing accessories, and with shockresistant no trace bumpers.

The head side is equipped with supports for drainage bags and bottle holder.

The backrest is moved by a bilateral lever and assisted by a pneumatic spring.

Light structure realized with steel profiles of high thickness and varnished with epoxy powders.

At the base wheels Ø 200 mm, one wivelling, one directional and fixed, 2 swivelling at head side with spring brake.

The brake is always inserted; to unlock it is sufficient to operate on the handle on the head side.

TECHNICAL DETAILS

Overall dimensions cm 204x70x78h

Base dimensions cm 198 x 58

Backrest inclination from 0° to 80°

Base height cm 78

Castors Ø 200 mm

Weight kg 48

Safe working load kg. 170

Height of the side rails from the sprung base cm 28

Medical device class I following Dir. 93/42 CEE
